ULTRA LOW TEMPERATURE FREEZER (-80°C)
Affordable and secure long
term storage solutions for biological
samples
Ultra-low temperature freezers are widely used in scientific research for long-term storage of samples. Cool Wind Scientific Systems offers high quality Ultra Low Temperature freezers, with internal volumes. CWS provides various design ranges considering the customer requirements. Also available as Blood Component Freezer for the storage of blood components.
The quality of the product is considered as the key factor in design without compromising the safety and ergonomic requirements. The combination of low power consumption, lowest noise level and the standard use of ecological, green refrigerants make it the most environmental friendly.
CWS offers ultra low temperature freezers in Student, Economic & Premium versions. Tailor made designs such as Portable / Table top freezers could also be made to suit the customer needs. Blood compo freezer model is also available on customer needs.
|
Temperature range |
-75°C to -80°C with 0.1°C display resolution and increment. |
|
Insulation thickness |
150mm PUF insulation for cabinet and 100mm for door. |
|
Cabinet material |
Stainless steel SS304 |
|
Outer material |
Powder coated CRCA |
|
Controller type |
PID controller with set & process value display |
|
Temp. sensor |
RTD type PT100 sensor |
|
Temp. deviation alarm |
Set value +/- 5°C |
|
Evaporator |
Plate and tube type |
|
Refrigerant |
R404a & R508b (CFC, HCFC free refrigerants) |
ACCESSORIES:
- Coolant Cassettes
- Cryo Vial Boxes
- Freezer Racks
- De-icing kit
- Ice Scrapers
- Cryogenic gloves
- Chart Recorders
- Voltage Stabilizers
STUDENT VERSION (SUFV / SUFH
Models):
Hermetically sealed, commercially available, India make compressors. Fixed/Removable shelves with acrylic sub doors for each (in upright freezers). Cam type latch to provide one handed operation and to ensure secure door closure. One year comprehensive warranty.
ECONOMIC VERSION (EUFV / EUFH
Models):
Similar to student version. But with imported compressors. Insulated sub doors for each shelf. IQ/OQ/PQ with NABL master traceability. Backup port for CO2 injection. Tools free filter access. Alarms for temperature deviation and condenser overload. One year comprehensive warranty.
PREMIUM VERSION (PUFV / PUFH Models):
Similar to economic version. But with two years comprehensive warranty. IQ/OQ/PQ certificate with NABL accreditation. Chart recorder (or) RS232 communication port as per customer requirements. Alarm for power failure, Door open, temperature deviation and condenser overload.
MODELS:
|
Catalog #
|
SUFV120 EUFV120 PUFV120 |
SUFV239 EUFV239 PUFV239 |
SUFV395 EUFV395 PUFV395 |
SUFV527 EUFV527 PUFV527 |
SUFV659 EUFV659 PUFV659 |
|
Capacity |
120 Litres |
239 Litres |
395 Litres |
527 Litres |
659 Litres |
|
Inner Dimensions L x B x H, mm |
320 x 430 x 870 |
480 x 430 x 1160 |
480 x 710 x 1160 |
640 x 710 x 1160 |
800 x 710 x 1160 |
|
Outer Dimensions L x B x H, mm |
620 x 730 x 1690 |
780 x 730 x 1980 |
780 x 1010 x 1980 |
940 x 1010 x 1980 |
1100 x 1010 x 1980 |
|
No. of Shelves |
3 |
4 |
4 |
4 |
4 |
|
No. of Racks |
6 |
12 |
12 |
16 |
20 |
|
Vial Boxes capacity |
90 |
180 |
300 |
400 |
500 |
|
|
|
Catalog #
|
SUFH130 EUFH130 PUFH130 |
SUFH246 EUFH246 PUFH246 |
SUFH392 EUFH392 PUFH392 |
SUFH492 EUFH492 PUFH492 |
SUFH657 EUFH657 PUFH657 |
|
Capacity |
130 Litres |
246 Litres |
392 Litres |
492 Litres |
657 Litres |
|
Inner Dimensions L x B x H, mm |
465 x 465 x 600 |
640 x 640 x 600 |
1020 x 640 x 600 |
1280 x 640 x 600 |
1710 x 640 x 600 |
|
Outer Dimensions L x B x H, mm |
1165x765x1020 |
1340x940x1020 |
1720 x 940 x 1020 |
1980 x 940 x 1020 |
2410 x 940 x 1020 |
|
No. of Racks |
9 |
16 |
24 |
32 |
36 |
|
Vial Boxes capacity |
90 |
160 |
240 |
320 |
360 |
|
|
|
