PLASMA FREEZER (-40°C)
Affordable and secure long term storage solutions for plasma storage.
CWS offers high quality Plasma Freezers that are suitable for blood plasma storage and erethrocyte concentrates. CWS Plasma Freezer featured with battery backup and RS232 communication interface (Chart Recorder will be provided as alternate for RS232 based on customer requirements.
Plasma Freezers are also available with Backup Refrigeration System.
|
Temperature range |
-30°C to -40°C with 0.1°C display resolution and increment. |
|
Insulation thickness |
75 mm PUF insulation for cabinet and 100mm for door. |
|
Cabinet material |
Stainless steel SS304 |
|
Outer material |
Powder coated CRCA |
|
Controller type |
PID controller (or NTC) with set & process value display |
|
Temp. sensor |
RTD type PT100 sensor (or NTC) |
|
Temp. deviation alarm |
Set value +/- 5°C |
|
Evaporator |
Plate and tube type |
|
Refrigerant |
R404a (CFC, HCFC free refrigerant) |
ECONOMIC VERSION (EDFV / EDFH Models):
Hermetically sealed, commercially available, India make compressors. Fixed/Removable shelves with acrylic sub doors for each (in upright freezers). Cam type latch to provide one handed operation and to ensure secure door closure. Tools free filter access. One year comprehensive warranty.
PREMIUM VERSION (PDFV / PDFH Models):
Similar to economic version. But with two years comprehensive warranty. IQ/OQ/PQ certificate with NABL accreditation. Chart recorder (or) RS232 communication port as per customer requirements. Alarm for power failure, Door open, temperature deviation and condenser overload.
|
Catalog #
|
PFV72 |
PFV156 |
PFV264 |
PFV352 |
PFV440 |
|
Capacity |
120 Litres |
239 Litres |
395 Litres |
527 Litres |
659 Litres |
|
Inner Dimensions L x B x H, mm |
320 x 430 x 870 |
480 x 430 x 1160 |
480 x 710 x 1160 |
640 x 710 x 1160 |
800 x 710 x 1160 |
|
Outer Dimensions L x B x H, mm |
470 x 580 x 1540 |
630 x 580 x 1830 |
630 x 860 x 1830 |
790 x 860 x 1830 |
1600 x 860 x 1830 |
|
No. of Shelves |
3 |
4 |
4 |
4 |
4 |
|
No. of Racks |
6 |
12 |
12 |
16 |
20 |
|
Blood Bags capacity (450ml) |
72 |
156 |
264 |
352 |
440 |
|
Catalog #
|
PFH108 |
PFH216 |
PFH360 |
PFH432 |
PFH504 |
|
Capacity |
130 Litres |
246 Litres |
392 Litres |
492 Litres |
657 Litres |
|
Inner Dimensions L x B x H, mm |
465 x 465 x 600 |
640 x 640 x 600 |
1020 x 640 x 600 |
2200 x 790 x 920 |
1710 x 640 x 600 |
|
Outer Dimensions L x B x H, mm |
1015 x 615 x 920 |
1190 x 790 x 920 |
1570 x 790 x 920 |
1980 x 940 x 1020 |
2260 x 790 x 920 |
|
No. of Racks |
9 |
16 |
24 |
32 |
36 |
|
Blood Bags capacity (450ml) |
108 |
216 |
360 |
432 |
504 |
